For a quarter of a century, Unisoft has been a leader providing innovative shop floor automation software to automate New Product Introduction (NPI).  With over a 1000 customers worldwide, Unisoft provides automation software for lean manufacturing in industries such as electronics, medical, chemicals, aerospace, pharmaceuticals, foods, textiles and other manufacturing industries.

For 25 years our goal has been to bring your products into production as fast as possible with the least amount of effort and at an affordable price.  Industry leaders look to Unisoft's Plant Execution System to integrate their shop floors. Our software is surprisingly low cost and provides customer solutions to the world's manufacturing industry with rapid product development, production and lower costs.  NPI has never been easier.

Unisoft clients range from start-ups to billion dollar companies. Our customers are located in countries worldwide and remark how easy and straight forward the software is to learn and use.

The Unisoft FACTORY software suite is a complete production floor solution for many industries.  For Electronics Manufacturing our software is used to quickly setup production equipment such as Automatic Pick & Place Assembly machines, AOI Inspection equipment, ATE/ICT PCB Test, Selective Solder machines, etc. The software also tracks product and job work orders, creates process assembly documentation, kitting labels, assembly cost and parts cost reports, etc.  As a customer you are allowed to distribute the Unisoft Free PC Board Viewer Software to your production floor, vendors, customers, etc. to aid assembly, fast 1st article inspection, general inspection, repair/rework, technician debug, for better communications, etc. (No need to purchase additional licenses).

Product and job tracking Manufacturing Execution Software (MES) is also available for all industries including electronics, medical, chemicals, aerospace, pharmaceuticals, foods, textiles, etc.

Founded in 1985 Unisoft offers a rich depth of software and the best pricing in the industry.  Call (203) 913-0782 for details.




    Free PCB Viewer Software
  Email:
                 Your email will be kept private.









Why Companies Choose Unisoft:        The History
                                                      The Clients
                                                      The Price











Unisoft FACTORY software suite addresses the major areas to automate your production floor:

1)  Use the PRONTO series of software modules for fast automatic setup of production equipment, communications, collaborative engineering, CAD translations, etc. including:

    • Assembly machine setup software.
    • Collaborative engineering and better communications.
    • Create process documentation, assembly instructions, kitting labels, costing reports, and process aids.
    • AOI and X-Ray Inspection equipment setup software.
    • ATE PCB Test and Test Fixture Design software.
    • Selective Solder machine setup software.
    • Importing of valuable CAD design data for use in your manufacturing processes.
    • CAD Translation software and services.

2)  Use the CELLS WORKFLOW Product Tracking MES software to track product and report progress:

    • Real time WIP inventory tracking as well as being able to enter fault data, trends, etc.
    • Online manufacturing documents and machine monitoring.
    • Order Status, SPC Process Control and Reports.
    • Routings - forced or non-forced out of sequence.
    • FDA compliant electronic data collection and WIP tracking system.
    • Fully internet enabled - Internet or Intranet integration.
    • Plant Execution System provides Manufacturing and Engineering Data Collection and analysis.
    • Open database - Share data with ERP, MRP and other executive systems.
    • more

The Unisoft FACTORY software suite is completely modular. Purchase only the software you require now and add modules as your needs  grow.





The Unisoft FACTORY software suite modules includes:

    ProntoPLACE - Used by electronics manufacturers ProntoPLACE creates programs for automatic assembly machines, process assembly sheets, 1st article inspection, etc.

    CELLS WORKFLOW Product Tracking MES SOFTWARE - Low cost Product Tracking MES Software

    ProntoVIEW-MARKUP - Used by electronics manufacturers ProntoVIEW-MARKUP displays the PC Board

     ProntoTEST-FIXTURE - Used by electronics manufacturers ProntoTEST-FIXTURE designs the "bed of nails" test fixture and generates circuit description files your Automatic Test Equipment (ATE).

    ProntoAOI - Used by electronics manufacturers ProntoAOI creates programs for quick setup and programming of Automatic Optical Inspection (AOI) machines.

    ProntoSELECTIVE-SOLDERING - Used by electronics manufacturers ProntoSELECTIVE-SOLDERING creates programs for quick setup and programming of Selective Soldering machines.

    ProntoGERBER CONNECTION - Imports raw Gerber data and allows the user to add intelligent information to the shapes on the display and create netlists, process assembly sheets, etc.

   CAD TRANSLATION SERVICES AND SOFTWARE - Unisoft translates your CAD or raw Gerber and BOM files into formats used to setup your manufacturing equipment. Also CAD to CAD translations, Gerber to Netlist conversions, etc..



Test drive today! - Click here to download the software products you are interested in.

Click here to download Unisoft FACTORY Suite literature in Adobe format.

Click here for a movie




The ProntoPLACE Placement-PRO module is used by electronics manufacturers to generate the necessary programs for automatic assembly machines in minutes. ProntoPLACE Placement-PRO programs most popular surface mount (SMT) placement, through-hole (THT) insertion and glue dispensing machines. Universal GSM HSP PUT RAD VCD, Fuji, Mydata, Siemens, Sony,  Panasonic, Quad assembly, Philips, Contact Systems (CS400, 3, C5 series, etc.), Camelot, and others are supported.  Also create assembly documents and work instructions via automatic assignment of unique colors and patterns to each part number on the assembly, add text and graphic annotations.     Call (203) 913-0782 for details.

    - Click here to download the ProntoPLACE software.

    - Click here for more details.

back to top



Quoting - Assembly Cost Estimate Report

Import your PC Board into the Unisoft software and you instantly receive a report containing component counts for top and bottom of the PC Board broken down by SMT, Fine pitch, BGA’s, Thru-hole, etc. with the cost for each group.  You can create as many Assembly Cost templates has you wish, for example one each for either a Low, Medium or High volume build. This is a great quoting time saver for Contract and OEM manufacturers.




PC Board:  SAMPLE
Date:  10-1-09
Estimated base build price total = $219.95

Device assembly total cost = $118.80
Part number total cost = $101.15
----

SMT 2 pins greater than 0402 package type:  Greater than .040 inch distance between pin 1 and 2.
      Top         -      4 = total device count,      8 = total pin count
      Bottom      -     78 = total device count,    156 = total pin count
      Part #'s    -      8 = total part numbers
      Base price:   $73.23 = (0.08 * device count) + (8.33 * part #'s)

SMT 8 pins and greater and 30 mils or less pin spacing (fine pitch):
      Top         -      3 = total device count,    144 = total pin count
      Bottom      -      0 = total device count,      0 = total pin count
      Part #'s    -      3 = total part numbers
      BGA's       -      0 = included in above count.
      Base price:   $25.36 = (0.12 * device count) + (8.33 * part #'s) + (0.18 * BGA count)





PLANT INTELLIGENCE- FACTORY FLOOR CONTROL

CELLS WORKFLOW™ - Gearing up the NEW Factory Floor^tm

Building military, medical, consumer products, etc?

Need to track every job in your factory?

Need instant status of every work and sales order on your production floor?

Within an hour you will be tracking your first product.


What is CELLS WORKFLOW?  CELLS WORKFLOW™ is affordable, straight forward
simple to setup yet powerful product and job tracking software. CELLS WORKFLOW product tracking software collects real-time data for all your product builds electronic or non-electronic. For both board and box build deliver build instructions and collect quality data from your assembly process while performing in-process serial registration and enforced routing ensuring quality processes are implemented. Know the WIP status of every unit in any work order and have all build history data available. CELLS WORKFLOW has been used by our customers for over 15 years.

An affordable complete Production Floor Management System. CELLS WORKFLOW Product Tracking MES Software provides low cost product tracking and the Factory Intelligence you need.  CELLS WORKFLOW embodies a straight forward methodology for tracking product and reporting progress.

CELLS WORKFLOW™ is a cost effective Manufacturing Execution System (MES) that provides process control for any industry.  CELLS WORKFLOW has a 15 year track record of excellence (FDA compliant / UL and ETL certification support).  The Unisoft CELLS WORKFLOW Plant Execution System includes complete product tracking at every work cell, collection data, material and labor traceability on the production floor, inventory tracking software, defect tracking software, repair loop, deliver & control documents, Statistical Process Control (SPC) quality reporting, PDM, PLM, interface to ERP and more. CELLS WORKFLOW is easy to implement, go-live in week one.   Call (203) 913-0782 for details.

    - Click here to download the CELLS WORKFLOW software.

    - Click here for more details.

back to top





The ProntoVIEW-MARKUP module is used by electronics manufacturers and is designed for use across the entire production floor from creating Process and Assembly aid documents for assembly personnel to finding shorts on the PC Board between two traces for troubleshoot technicians.  ProntoVIEW-MARKUP has a multitude of features that aids every department such as design, assembly, first article inspection, test, CAD viewer, repair/rework, PCB troubleshooting, etc.  ProntoVIEW-MARKUP increases efficiency, communications and reduces errors.

ProntoVIEW-MARKUP creates assembly documents and process documents with automatic assignment of unique colors and patterns to each part number on the assembly.   Assign text and graphic annotations. ProntoVIEW-MARKUP quickly finds components, pins, shorts between traces, built-in paperless schematic, etc. Exports a standard Netlist, X/Y file and more.  A free SHAREWARE copy of the ProntoVIEW-MARKUP software is available.   Call (203) 913-0782 for details.



    - Click here to download the ProntoVIEW-MARKUP software.

    - Click here for more details.
